EVALUATION KIT
eBike Torque & Cadence Evaluation Kit
High-precision magnetomechanical sensing platform for pedal assist systems, rider torque measurement, and cadence detection.
Contactless Torque Sensing
Integrated Cadence Output
UART Interface
Up to 150 Nm
Sample Price
€ 499
Starting price for evaluation sample configuration.
Volume pricing available for OEM quantities &
integration programs.
Lead Time
4 - 6 Weeks
Depending on production schedule
and availability.
Ready to evaluate in your application?
Price indication and lead time are provided for initial evaluation planning and may vary depending on configuration and availability.
TORQUE RANGE
Up to 150 Nm.
INTERFACE
UART
BANDWIDTH
200 Hz
CADENCE OUTPUT
Quadrature A/B
EVALUATION KIT
The AD-TEC eBike Torque & Cadence Evaluation Kit is designed to simplify the evaluation of our contactless magnetomechanical torque sensing technology with integrated cadence detection.
The platform delivers highly accurate torque measurements together with speed information for advanced eBike control, rider power measurement, and smart mobility applications.
- High accuracy across a wide torque range
- Robust against misalignment and harsh environments
- Wear-free and contactless sensing
- Easy integration via UART interface
- Pre-calibrated and ready to use
KIT Content
Torque Sensor Unit
Pre-calibrated torque sensor with integrated cadence sensing.
USB-TTL Converter
UART communication interface for connection to PC.
USB Cable
USB connection cable for power and data communication.
Documentation Package
Datasheet, connection information, and evaluation guidance.
Applications
eBikes
Pedal Assist Systems
Smart Mobility
Rider Power Measurement
eMobility Platforms
Technical Specifications
Torque Sensor
Torque Range Up to 150 Nm
Accuracy ±1.5 %FS
Band Width(-3db) 200 Hz
Repeatability 0.2 %FS
Hysteresis 1.5 %FS
Operating Temp 0° to 70°C
Cadence Sensor
Output Type Quadrature A/B
Channels 2
Pulses / Rev 18 PPR
Max Angular Error ±1°
Max Speed 200 RPM
Sensor interface
Interface UART
Baud Rate 115200
Supply Voltage 5V DC
Repeatability 0.2 %FS
Current Consumption < 50 mA
Need a customized sensing solution?
AD-TEC also supports OEM integration and application-specific sensor development tailored to your requirements.
